GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-59
Section 8-6 Rear Panel Assy (110V/ 220V FRU P/N: 5313708)
8-6-1 Rear Panel Assy (FRU No. 5313708)
This is a description on how to remove and replace the Rear Panel Assy.
8-6-1-1 Tools
• Common Phillips screwdrivers
8-6-1-2 FRU BOM. This FRU Kit P/N:5313708 consists of following parts.
Table 8-3 110 V Rear Panel
Table 8-4 220 V Rear Panel
8-6-1-3 Needed Manpower
1 persons, 15 minutes
8-6-1-4 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-6-1-5 Removal Procedure
1) Remove the rear cover. Refer section 8-4-3 on page 30
Part Number Description
5313708
Rear Panel Asm
5314500
Rear_Panel_Rating_Label_100V_Lakshya
Part Number Des
5313708
Rear Panel Asm
5314494
Rear_Panel_Rating_Label_220V_Lakshya
