GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-15
8-2-8 TGC PWA FRU Assy (FRU P/N :5315107)
This is a description on how to remove and replace the TGC PWA Assembly.
8-2-8-1 Tools
• Common phillips screwdrivers
8-2-8-2 FRU BOM
This FRU Kit P/N:5315107 consists of following parts.
8-2-8-3 Needed Manpower
• 1 person, 10 minutes
8-2-8-4 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-2-8-5 Removal procedure
1) Remove keyboard Assembly. Refer section 8-2-7 on page 11
2) Remove TGC Caps. ( 8 Nos.)
3) Remove TGC assembly by removing the four screws (as marked in Figure 8-14 on page 8-16 )
PWA with TGC interface cable.
PART NO DESCRIPTION
5270371 TGC PWA
5269755 TGC Cable Assembly
5314202 Fastener- M3 X 4 Spring_washer_type
