8-40 Section 8-4 - Mechanicals
8-4-6 Caster Wheel Front (FRU P/N :5315118) / Caster Wheel Rear (FRU P/N :5315119)
This is a description on how to remove and replace the castor wheel front and castor wheel rear.
8-4-6-1 Tools
• Common Phillips screwdrivers; Allen Key Set.
8-4-6-2 FRU BOM.
This FRU Kit P/N:5315118 front and FRU Kit P/N:5315119 Rear consists of following parts.
Table 8-1 Front
Table 8-2 Rear
8-4-6-3 Needed Manpower
• 1 person, 15 minutes each
8-4-6-4 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-4-6-5 Removal Procedure
1) Remove the Transformer assy. Refer section 8-8-1 on page 75
2) Lift the system slightly up on the side of the castor wheel that needs replacement
3) Place a small block of the size of castor wheel to balance the system
PART NO DESCRIPTION
5314415 CASTER_FRONT_LOCK_Lakshya
2372269 CAPSCREW M8X20 BLACK
PART NO DESCRIPTION
5314416 CASTER_REAR_Lakshya
2372269 CAPSCREW M8X20 BLACK
