IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-19
8-2-10 Optical Trackball Assy (FRU P/N :5315029)
This is a description on how to remove and replace the Optical Trackball Assembly.
8-2-10-1 Tools
• Common phillips screwdrivers
8-2-10-2 FRU BOM
This FRU Kit P/N:5315029 consists of following parts.
8-2-10-3 Needed Manpower
• 1 person, 10 minutes
8-2-10-4 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-2-10-5 Removal procedure
1) Remove Keyboard Assembly. Refer section 8-2-7 on page 11.
2) Unfasten the 2 screws (A,B) holding the trackball bracket (circled in Yellow color in Figure 8-16 on
page 8-20 )
PART NO DESCRIPTION
5184376 Optical-Trackball
5268980 4 pin Trackball cable
5264458 Trackball 6 Pin cable
2334841 fasteners- M3 X 8 ECO-FIX
To Next Page
