Section 8-3 Keyboard Rear Cover Assy (FRU P/N: 5315122 )
8-3-1 This is a description on how to remove and replace the keyboard cover Assembly.
8-3-1-1 Tools
• Common phillips screwdrivers
8-3-1-2 FRU BOM
This FRU Kit P/N:5315122 consists of following parts.
8-3-1-3 Needed Manpower
• 1 person, 15 minutes
8-3-1-4 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-3-1-5 Removal procedure
1) Remove Keyboard assembly. Refer Section 8-2-6
Figure 8-17 Keyboard
2) Remove the 2 screws (A,B) as shown in the figure above.
3) Remove LCD Arm cover as mentioned. Refer section 8-2-4 on page 8- 7
PART NO DESCRIPTION
5310092 Rear_Cover_Lakshya
2334843 Fasteners- M4 X 6 ECO-FIX
A
B
