GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-83
Section 8-12 Power Cable Set (FRU P/N: 5315036)
8-12-0-1 Tools
• Common Phillips screwdrivers
8-12-0-2 FRU BOM
This FRU Kit P/N:5315036 consists of following parts.
NOTE: This individual cables are not seperate FRUs, but are part of cable kit higher level FRU
8-12-0-3 Needed Manpower
• 1 persons, 15 minutes per cable
8-12-0-4 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-12-0-5 Removal Procedure
1. Remove the covers and parts as applicable. Refer to the applicable section of this document.
2. Unplug the power cable from both the ends.
8-12-0-6 Functional Checkout Procedure
Part Number Description
5270783 Cable Assembly for Transformer to PS, SSR and Peripheral Connector
5262720 Cable Assembly for Panel mount connector to power supply & solid state relay
5262046 Peripheral Connector to Rear panel sockets
5269059 PDB to Conn Brd and MST Brd
5269791 LCD Power cable
5269919 Dual SATA Power Cable for PDB to HDD and DVD
5270870 PDB to KBD and Fan
5269067 Conn Brd to TXB
5263747 Docking Brd to RP2 FRC cable
See
Section
Functional Test Debrief Script
4-3-1 Power On/Boot Up
Service Manual Direction 5344303-100, Rev 2, Section 8-13-0. Equipment passes all
required tests and is ready for use.
4-3-2 Power Off/ Shutdown
