GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 55344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
7-22 Section 7-6 - Troubleshooting
7-6-2 Peripheral Troubleshooting Trees
7-6-2-1 Unable Recording by Printer
Figure 7-18 Unable Recording by Printer
Unable to record by the Printer!
1) Check power supply connection to
the printer.
2) Check the printer connection to the
system.
YES
NO
Is the connection set in the
right way?
Are there printer papers
left?
Insert the printer papers.
NO
YES
Is the proper configuration
for P* key set?
Set the P* key by the Utility menu.
NO
Change printer.
END
YES
To Next Page
