IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
8-54 Section 8-4 - Mechanicals
3) Remove SATA cable from Hard disk drive assembly. Refer Figure 8-48 on page 8-54
Figure 8-48 Removing SATA cable
8-4-11-6 Mounting procedure
1.) Install the new parts in the reverse order of removal.
8-4-11-7 Functional Checkout Procedure
See
Section
Functional Test Debrief Script
4-3-1 Power On/Boot Up
Service Manual Direction 5344303-100, Section 8-4-11. Equipment passes all
required tests and is ready for use.
4-3-2 Power Off/ Shutdown
Sata Signal Cable
Power cable
