GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-17
8-2-9 Alpha Numeric Keyboard with cables (FRU P/N :5340669)
8-2-9-1 Tools
• Common phillips screwdrivers
8-2-9-2 FRU BOM
This FRU Kit P/N:5340669 consists of following parts.
8-2-9-3 Needed Manpower
• 1 person, 30 minutes
8-2-9-4 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-2-9-5 Removal procedure
1) Remove Keyboard Assembly. Refer section 8-2-7 on page 11
2) Remove the Alphanumeric Keyboard by unfastening the 10 screws (marked in Red color in
Figure 8-15 on page 8-18 ) holding it and the Alphanumeric keyboard cable.
PART NO DESCRIPTION
5123732
AN KBD
5310048 A_N_Brkt_Lakshya
5184104 fasteneres- M2.9_Self_Taping_Screw
