GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
8-82 Section 8-11 - Signal Cable Set (FRU P/N: 5315042)
Section 8-11 Signal Cable Set (FRU P/N: 5315042)
8-11-0-1 Tools
• Common Phillips screwdrivers
8-11-0-2 FRU BOM
This FRU Kit P/N:5315042 consists of following parts.
NOTE: This individual cables are not seperate FRUs, but are part of cable kit higher level FRU
8-11-0-3 Needed Manpower
• 1 persons, 15 minutes per cable
8-11-0-4 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-11-0-5 Removal Procedure
1. Remove the covers and parts as applicable. Refer to the applicable section of this document.
2. Unplug the signal cable from both the ends.
8-11-0-6 Functional Checkout Procedure
Part Numbers Description
5265925 LCD signal Cable
5262402 Docking Brd to Speaker
5273129 SATA signal Cable for HDD
5266424 Keyboard ground Cable
5272618 Fan Cable Assembly
5269755 TGC Interface Cable
5268980 Track ball 4 pin interface
5264458 Track ball 6 pin interface
5267353 Encoder PCB 15 pin interface
5263844 MST to KBD & DVD SATA Signal cable
See
Section
Functional Test Debrief Script
4-3-1 Power On/Boot Up
Service Manual Direction 5344303-100, Section 8-12-0. Equipment passes all
required tests and is ready for use.
4-3-2 Power Off/ Shutdown
