GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-9
8-2-6 Handle P3 Console (FRU P/N :5315120)
This is a description on how to remove and replace the Handle P3 console Assembly.
8-2-6-1 Tools
• Common phillips screwdrivers; Allen Key Set.
8-2-6-2 FRU BOM
This FRU Kit P/N:5315120 consists of following parts.
8-2-6-3 Needed Manpower
• 1 person, 15 minutes
8-2-6-4 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-2-6-5 Removal procedure
1) Remove keyboard Top cover and Pull out the keyboard top assembly cover by the slot marked in the
Figure 8-8 on page 8-10
2) Remove Gel holder and probe holder. Refer section 8-3-2 on page 23
PART NO DESCRIPTION
5310098 Handle
2372269 CAPSCREW M8X20 BLACK
To Next Page
