9-12 Section 9-8 - Flex Pcb Cables
Section 9-8Flex Pcb Cables
Wiring Diagram Refer Chapter 5 page 5-8.
Figure 9-88 Cable Assy
Item Part Name Part Num Description Quantity
501
Flex Cable (Con to Tx) 5315108 Flex Cable (Con to Tx)
1
502
Flex Cable (MST to TX) 5315109 Flex Cable (MST to TX)
1
502
501
