GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-43
4) Remove Rear-side EMI cover. Refer Figure 8-36 on page 8-43 for details on how to remove Rear
cover.
Figure 8-36 Rear-side EMI cover
8-4-7-6 Mounting procedure
1.) Install the new parts in the reverse order of removal
8-4-7-7 Functional Checkout Procedure
Functional Test Debrief Script
Do Visual Inspection and ensure
no scratches observed and
fitment is done properly
Service Manual Direction 5344303-100, Section 8-4-7. Equipment passes all required
tests and is ready for use.
Rear-side
EMI cover
Software DVD
