8-16 Section 8-2 - Disassembly/Re-assembly of VIVID P3
Figure 8-14 TGC PCB
8-2-8-6 Mounting procedure
1.) Install the new parts in the reverse order of removal.
8-2-8-7 Functional Checkout Procedure
See
Section
Functional Test Debrief Script
4-3-1 Power On/Boot Up
Service Manual Direction 5344303-100, Section 8-2-7. Equipment passes all required
tests and is ready for use.
4-3-2 Power Off/ Shutdown
4-3-6 B Mode Checks
TGC Interface
cable
TGC Assembly
