GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
8-56 Section 8-5 - USB Cable Set (FRU P/N: 5315039)
8-5-1 LV and Power distribution Board (Part No: 5315028) / Power distribution Board
Assembly (Part no: 5315104)
8-5-1-1 Tools
• Common Phillips screwdrivers
8-5-1-2 FRU BOM FOR LV & PDB. This FRU Kit P/N:5315028 consists of following parts.
8-5-1-3 FRU BOM FOR PDB. This FRU Kit P/N:5315104 consists of following parts.
8-5-1-4 Needed Manpower
• 1 person, 15 minutes
8-5-1-5 Preparations
Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-5-1-6 Removal Procedure
1) Loosen the two screw (A) and pull out the cables which are connected to PDB as shown in rectangle
box (B) in the Figure 8-47 on page 8-53
PART NO DESCRIPTION
5273204 Low voltage Power supply
5308961 Power supply Bracket
2334842 Fasteners- M3 X 6 ECO-FIX
PART NO DESCRIPTION
5269602 Power Distribution Board
5215245 SSR with cable
5308962 Power distribution Bracket
2139752 Fastener- STR.SCR M3 X 8
To Next Page
