IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-57
2) Remove LV and PDB assembly. Refer Figure 8-47 on page 8-53
Figure 8-49 Removing Hard Disk Drive Power cable
3) Remove SATA cable from Hard disk drive assembly. Refer Figure 8-48 on page 8-54
Figure 8-50 Removing SATA cable
(B) Power cables
(A) Two Screws
(B) Power cable
PDB Bracket
To Next Page
