8-18 Section 8-2 - Disassembly/Re-assembly of VIVID P3
8-2-9 Alpha Numeric Keyboard with cables (FRU P/N :5340669) (cont’d)
Figure 8-15 Alpha Numeric keyboard PCB
8-2-9-6 Mounting procedure
1.) Install the new parts in the reverse order of removal.
8-2-9-7 Functional Checkout Procedure
See
Section
Functional Test Debrief Script
4-3-1 Power On/Boot Up
Service Manual Direction 5344303-100, Section 8-2-8. Equipment passes all required
tests and is ready for use.
4-3-2 Power Off/ Shutdown
4-3-6 B Mode Checks
A/N Keyboard
10 Screws
To Next Page
