GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
3-14 Section 3-6 - System Configuration
Section 3-6
System Configuration
3-6-1 System Specifications
3-6-1-1 Physical Dimensions
The physical dimensions of the VIVID P3 console are summarized in Figure 3-9 on page 3-14 .
Table 3-4 Physical Dimensions of VIVID P3
Height Width Depth Unit
1347 445 595 mm
53.0 17.5 23.4 inches
Figure 3-9 Overall Dimensions
