GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
8-42 Section 8-4 - Mechanicals
8-4-7 Rear EMI Cover (Part of EMI Cover Assy FRU P/N :5315111)
This is a description on how to remove and replace the Right EMI Cover (P/N: 5308951).
8-4-7-1 Tools
• Common Phillips screwdrivers
8-4-7-2 FRU BOM
This FRU Kit P/N:5308951 consists of following parts.
8-4-7-3 Needed Manpower
• 1 person, 15 minutes
8-4-7-4 Preparations
• Shutdown the system and switch off the main Circuit Breaker at the bottom rear side of the system.
8-4-7-5 Removal Procedure
1) Remove Right cover. Refer section 8-4-3 on page 30 for details on how to remove Right cover.
2) Remove rear cover. Refer section 8-4-3 on page 30
3)Use the scewdriver and loosen the five screws (1,2,3,4,5)
PART NO DESCRIPTION
5308951 Rear EMI cover
2334842 Fastener- M3 X 6 ECO-FIX
