GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
9-2 Section 9-3 - Operator Console Assy
Section 9-3Operator Console Assy
Figure 9-81 OPERATOR CONSOLE ASSY
1. Peripheral Device (Signals I/O Port, Power In) 9. Gel Holder
2. Three Probe Port 10. VGA Connector
3. ECG 11. Ethernet Connector
4. DVD-RW Drive 12. S Video Connector
5. Monitor 13. BNC Connector
6.USB Port 14. USB Ports
7. B/W Printer Option 15. Circuit Breaker
8. Probe Holder 16. Power Connector
