GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
8-60 Section 8-6 - Rear Panel Assy (110V/ 220V FRU P/N: 5313708)
2) Loosen the five screws (1,2,3,4) of rear panel assembly of the system. Refer Figure 8-51 on page 8-
60
Figure 8-51 Rear pannel Assembly
3) Push upwards and pull out the Rear panel assembly by the slot marked (A,) in the Figure 8-52 on
page 8-61
Rear panel Assy
Software DVD
