GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5344303-100, REVISION 3 VIVID P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-61
4) Remove Rear panel assembly from the system Slide upwards as shown below Figure 8-52 on page
8-61
Figure 8-52 Removing Rear panel assembly
5) Disconnect the FRC cable, Power cable and USB Cables from rear pannel assembly. Refer Figure
8-53 on page 8-61
Figure 8-53 Removing FRC & USB cables
