1.2.2 Icons List on the Screen
Icon/info. Descripon
Alarm sound is mute/o
Waveform frozen symbol
Cross cursor for S-T segment measurement
Heart-beat symbol
Breath symbol
AC Power supply and the baery is fully charged.
The red blinking exclamatory mark means baery will be used out soon and needs to
charged. Alarm informaon area will show “Low Baery” message.
Charging status
/ /
One/two/ full grid baery voltage le
S-T +
.....
The measured S-T value
PI Perfusion index
% Unit of SpO
2
mmHg/kPa Unit of blood pressure
Bpm Unit of heart rate or pulse rate
rpm Unit of respiraon rate
°C/°F Unit of temperature
mm/s Unit of waveform sweeping speed
NOTE: some symbols may not appear on your equipment
