DLCI: 100, IP InARP 100.100.1.1, Serial2/1/0
The VC identified by DLCI 100 is mapped to the peer
IP address 100.100.1.1 through InARP. The VC is
configured on the interface Serial 2/1/0. If the
InARP
keyword is not displayed, the address-to-DLCI map
is a static map manually configured.
Creation time: 2012/10/21 14:48:44 Time when the map was created.
Status: Active
State of the address-to-DLCI map:
• Active.
• Inactive.
The state of an address-to-DLCI map is the same as
the state of the mapped VC.
Related commands
fr inarp
fr map ip
display fr pvc
Use display fr pvc to display information on F rame Relay PVCs and s tatistics about sent and
received data.
Syntax
display fr pvc [ interface interface-type interface-number ] [ dlci dlci-number ]
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
interface interface-type interface-number: Specifies an interface by its type and number. It can be a
main interface or subinterface. If you specify a main interface, this command displays information for
the main interface and its subinterfaces. If you specify a s ubinterface, this command displays
information for the subinterface. If you do not specify an i nterface, this command displays
information for all interfaces.
dlci dlci-number: Specifies a PVC by its DLCI in the range of 16 to 1007. If you specify a PVC, this
command displays detailed information about the PVC. If you do not specify a PVC, this command
displays brief information about PVCs. In addition to the brief information, the detailed information
includes Frame Relay traffic management information.
Examples
# Display brief information on all Frame Relay PVCs and statistics about sent and received data.
<Sysname> display fr pvc
PVC information for interface Serial2/1/0 (DTE, physically up)
DLCI: 100 Type: Dynamic Interface: Serial2/1/0
Encapsulation: IETF Broadcast
Creation time: 2012/04/01 23:55:39 Status: Active
Input: 0 packets, 0 bytes, 0 dropped
Output: 0 packets, 0 bytes, 0 dropped
