H3C UniServer R6900 G3

11-12
Drive configuration Storage controller NVMe SSD expander
16SFF
(8 SFF SAS/SATA drives
and 8 SFF NVMe drives)
1 × storage controller
1 × 8-port NVMe SSD expander module
16SFF
(4 SFF SAS/SATA drives
and 12 SFF NVMe drives)
1 × storage controller
• 1 × 4-port NVMe SSD expander module
• 1 × 8-port NVMe SSD expander module
16SFF
(16 SFF NVMe drives)
N/A 2 × 8-port NVMe SSD expander modules
12SFF (12 SFF SAS/SATA
drives)
2 × storage controllers N/A
12SFF
(8 SFF SAS/SATA drives
and 4 SFF NVMe drives)
1 × storage controller 1 × 4-port NVMe SSD expander module
12SFF
(4 SFF SAS/SATA drives
and 8 SFF NVMe drives)
1 × storage controller 2 × 4-port NVMe SSD expander modules
12SFF
(4 SFF SAS/SATA drives
and 8 SFF NVMe drives)
1 × storage controller 1 × 8-port NVMe SSD expander module
12SFF
(12 SFF NVMe drives)
N/A
• 1 × 4-port NVMe SSD expander module
• 1 × 8-port NVMe SSD expander module
8SFF
(8 SFF SAS/SATA drives)
1 × storage controller N/A
8SFF
(4 SFF SAS/SATA drives
and 4 SFF NVMe drives)
1 × storage controller 1 × 4-port NVMe SSD expander module
8SFF
(8 SFF NVMe drives)
N/A 2 × 4-port NVMe SSD expander modules
8SFF
(8 SFF NVMe drives)
N/A 1 × 8-port NVMe SSD expander module
4SFF
(4 SFF SAS/SATA drives)
1 × storage controller N/A
4SFF
(4 SFF NVMe drives)
N/A 1 × 4-port NVMe SSD expander module
Table 11-11 Drive population (16SFF server)
Drive
configuration
Drive cage bay
1 in compute
module 1
Drive cage bay
2 in compute
module 1
Drive cage bay
3 in compute
module 2
Drive cage bay
4 in compute
module 2
16SFF
(16 SFF SAS/SATA
drives)
4 SFF SAS/SATA
drives
4 SFF SAS/SATA
drives
4 SFF SAS/SATA
drives
4 SFF SAS/SATA
drives
