MAINTENCE AND ADJUSTMENT OF THE UTV
- 109 -
Periodic oil change : 0.25 L (0.22 Imp qt)
Total amount :
0.4 L (0.35 lmp qt, 0.42 US qt)
WARNING
:
Take care not to allow foreign material to enter
the final gear case.
·Install:
oil filler plug
23 Nm (2.3 m · kg, 17 ft · lb)
CHECKING THE DIFFERENTIAL GEAR OIL
1. Place the vehicle on a level surface.
2. Remove:
·oil filler plug ①
3. Check:
·oil level
Oil level should be up to the brim of hole.
Oil level low
Add oil to proper level.
WARNING
:
Take care not allow foreign material to enter the
differential gear case.
4. Install:
·oil filler plug
23 Nm (2.3 m · kg, 17 ft · lb)
CHANGING THE DIFFERENTIAL GEAR OIL
1. Place the vehicle on a level surface.
2. Place a receptacle under the differential gear
case.
3. Remove:
·oil filler plug ①
4. Drain:
·differential gear oil
..
