ENGINE
- 176 -
Gearcase transmission
No. Part Name Qty Remarks
Removing the gearcase transmission Remove the parts in the order listed.
Gearcase separation
1 Oil seal/ Bushing 1/1
2 Main shaft transmission assembly 1
3 L gear driving gear/ bearing 1/1
4 H gear driving gear/needle bearing 1/1
5 Main shaft/dowel pin 1/1
6 Main shaft Bearing press plate/ Bearing 1/1
7 Countershaft transmission assembly 1
8 Needle bearing Ⅰ 1
9 Needle bearing Ⅱ/washer 1/1
10 Countershaft 1
To Next Page
