CHASSIS
- 208-
REPLACING THE REAR BRAKE PADS
1. Check:
• brake pad
• brake pad plate
Damage/wear
Replace
2. Measure:
• brake pad thickness
Out of specification
Replace the brake
pads as a set.
Brake pad wear limit
1.0 mm (0.04 in)
3. Install:
• brake pads
• pad spring
NOTE:
Always install new brake pads, new brake pad
shims, new insulators, and a new brake pad
spring as a set.
4. Check:
• brake fluid level
• minimum level mark ①
Should the fluid level falls under the minimum
mark, please refill the box with the same type of
fluid as was recommended by the manufacturer to
ensure the fluid level is higher than the minimum
mark.
Must use DOT4 Brake Fluid
