ELECTRICAL COMPONENTS

- 282 -

ELECTRICAL

ELECTRICALCOMPONENTS

1. Thermo switch 2

2. Radiator fan

3. Brake light switch

4. Thermo switch 1

5. Ignition coil 1

6. Gear position switch

7. Reverse switch

8. Speed sensor

9. Ignition coil 2

10. stator assembly
