CHASSIS SPECIFICATIONS
Item Standard Limit
Steering system
Type Rack and pinion ----
Front suspension
Shock absorber travel
Spring free length
Spring fitting length
Spring rate
Stroke
58 mm (2.28 in)
320 mm (12.60 in)
245 mm (9.65in)
21 N/mm(2.1kg/mm, 117.60lb/in)
75-165 mm (2.95 ~ 6.49in)
----
----
----
----
Rear suspension
Shock absorber travel
Spring free length
Spring fitting length
Spring rate
Stroke
81 mm (3.19 in)
328 mm (12.91 in)
273.2 mm (10.76 in)+
44.1 N/mm (4.41 kg/mm, 246.95 lb/in)
117.7N/mm (11.77kg/mm, 659.08 lb/in)
0 ~ 60 mm (0 ~ 2.36 in)
60 ~ 81 mm (2.36 ~ 3.19in)
----
----
----
----
----
----
----
Front wheel
Type
Rim size
Rim material
Rim runout limit radial
lateral
Aluminum Alloy wheel
12 ×6.0 AT
ST12/ZL101A
----
----
----
----
----
1.0 mm
(0.04in)
1.0 mm
(0.04 in)
Rear wheel
Type
Rim size
Rim material
Rim runout limit radial
lateral
Panel wheel
12×8.0 AT
Steel
----
----
----
----
----
2.0 mm
(0.08 in)
2.0 mm
(0.08 in)
Brake lever and brake pedal
Accelerator pedal free play
Brake pedal free play
Parking brake cable free play
2 ~ 3mm (0.079 ~ 0.118 in)
2 ~ 3mm (0.079 ~ 0.118 in)
2 ~ 3 mm (0.079 ~ 0.118 in)
----
----
----
