CHASSIS
- 220-
CHECKING THE WHEEL TYRE
1. Check:
• wheel tyre
2. Measure:
• wheel runout
Over the specified limit
Replace the
wheel or check the wheel bearing play .①
3. Check:
• wheel balance
Out of balance 
Adjust.
Wheel runout limit
Radial ②: 2.0 mm (0.08 in)
Lateral ③: 2.0 mm (0.08 in)
WARNING:
The profile depth falls below 3mm, Please
replace the tyre immediately.
• tire wear limit
○
a
CHECKING THE WHEEL HUB
1. Check:
• wheel hub ①
Cracks/damage
Replace.
• splines (wheel hub) ②
Wear/damage
Replace.
·nuts (wheel hub)
loosen or distorted
Replace or tighten
