Oil cooler

No. Part Name Qty Remarks

Removing the oil cooler

1 Oil cooler assembly 1

2 Bolt ,flange M6×25 4

3 Flanging collar Φ6×Φ9×Φ19×11 4

4 Oil cooler 1

5 Screw ST3.9×15 4

Rubber oil Pipe Ⅰ Φ17×Φ10×870

Rubber oil Pipe Ⅱ Φ17×Φ10×500

8 Metal oil Pipe 2

9 Pipe clip Φ10-Φ20 8

10 Oil pipe clip 3
