CHASSIS

- 264-

Oil cooler

No. Part Name Qty Remarks

Bolt ,flange M6×12

Rubber oil Pipe Ⅳ Φ17×Φ10×350

Rubber oil Pipe Ⅲ Φ17×Φ10×350

14 Oil cooler parts 1

15 H-type rubber ring Φ9×Φ12×Φ19×10×3 4

16 Oil cooler breathing bolt 1
