Hisun HS800UTV - Cylinder Head and Cylinder Head Cover

ENGINE
- 131 -
CYLINDER HEAD AND CYLINDER HEAD COVER
No. Part Name Qty Remarks
Removing the cylinder head and
cylinder head
Remove the parts in the order listed.
1 Thermostat cover 2
2 Thermostat 1
3 Cylinder water outlet connector 1
4 Washer 1
5 O-ring 2
6 Cylinder head cover 2
7 Cylinder cover pad 2
8 Spark plug 2
9 Temperature sensor 1
10 Cylinder head 2
11 Timing chain tensioner cap bolt 2
12 Timing chain tensioner/gasket 2
