CHASSIS
- 229-
Front Bridge
DISASSEMBLING THE UNIVERSAL JOINT
Remove:
• universal joint
a. Remove the circlips . ①
b. Place the universal joint in a press.
c. With a suitable diameter pipe ben② - eath the
yoke , press the bearing ③ into the pipe as ④
shown.
d. Repeat the steps for the opposite bearing.
e. remove the yoke.
NOTE:
It may be necessary to lightly tap the yoke with
a punch.
