MAINTENCE AND ADJUSTMENT OF THE UTV
- 94 -
CHASSIS
CLEANING THE AIR FILTER
NOTE:
There is a check hose at the bottom of the①
air filter case. If dust and/or water collect in
this hose, clean the air filter element and air
filter case.
1. Remove:
·driver seat
·passenger seat
·console
·air filter case cover ①
·air filter element assembly ①
·air filter element cap ②
·air filter element③
NOTE:
Never operate the engine with the air filter
element removed. This will allow unfiltered air to
enter, causing rapid wear and possible engine
damage. Additionally, operation without the
filter element will affect carburetor tuning with
subsequent poor performance and possible
engine overheating.
2. Check:
·air filter element
·Damaged
Replace.
3. Clean:
·air filter element
a. Wash the element gently, but thoroughly in
solvent.
.
