Hisun HS800UTV - Transmission System; Front Bridge

CHASSIS
- 223-
TRANSMISSION SYSTEM
Front Bridge
No. Part Name Qty Remarks
Removing the front bridge (L.&R.)
1 Circlip 2
2 Double off-set joint assembly 4
3 Circlip 4
4 Ball bearing 4
5 Circlip 4
6 Boot band 4
7 Dust band 4
8 Boot band 4
9 Joint shaft assembly 2
10 C.V. Axle, front Bridge 2
