CHASSIS

- 215-

FOOTREST ASSEMBLY

No. Part Name Qty Remarks

Removing the footrest

1 Left corner panel 1

2 Screw 3

3 Nut, spring 7

4 Right coner panel 1

5 Screw 6

6 Nut, spring 5

7 Left foortest 1

8 Screw 8

9 Nut, spring 2
