ELECTRICAL COMPONENTS
- 285 -
Checking the switch continuity
Refer to “CHECKING THE SWITCH” and check for continuity between lead terminals. Poor connection,
no continuity Correct or replace.
* The coupler locations are circled.
1. Fuse
2. Brake light switch
3. Main switch
4. On-Command four-wheel drive switch and differential gear lock switch
5.Light switch
6.Parking brake switch
7.Reverse switch
8.Four-wheel drive switch
