CHASSIS

- 204-

REAR BRAKE CALIPER

No. Part Name

Qty Remarks

Removing rear brake caliper

1 Brake caliper assembly 1

2 Nut 6

3 Bolt 6

4 Brake disc 1

5 Bolt, flange 2

6 Brake pad holding bolt 2

7 Brake caliper assembly 1

8 Brake, pad 1
