CHASSIS

- 205-

No. Part Name

Qty Remarks

9 Brake pad (piston side) 1

10 Insulator/pad shim 2/2

11 Pad spring 1

12 Parking brake arm nut 1

13 Set bolt 1

14 Parking brake arm 1

15 Parking brake arm shaft 1

16 Spring 1

17 Parking brake case bolt 2
