Hisun HS800UTV - Engine; Adjusting the Valve Clearance

MAINTENANCE AND ADJUSTMENT OF THE UTV
- 85 -
ENGINE
Adjusting the valve clearance
NOTE:
·The valve clearance must be adjusted when the
engine is cool to the touch.
·
A
djust the valve clearance when the piston is at
the Top Dead Center TDC) on the compression
stroke.
·Remove:
·driver seat
·passenger seat
·console
1. Remove following parts：
① spark plug
② air-intake valve cover
③ Ignition signal sensor
④ left front cover, crank case
⑤ bolt M6 x 10
⑥ cylinder #1
⑦ cylinder #2
2. Remove：
① remove the bolts ⑤
② Ignition signal sensor
③ left front cover crankcase
④ cylinder cover
