CHASSIS

- 249-

CHECKING THE FRONT SHOCK ABSORBER

1. Check:

• shock absorber rod

Bends/damage

Replace the shock

absorber assembly.

• shock absorber assembly

Oil leaks

Replace the shock absorber

assembly.

• spring

Fatigue

Replace the shock absorber

assembly.

Move the spring up and down.
