Hisun HS800UTV - Starter Motor and Oil Filter

ENGINE
- 152 -
STARTER MOTOR AND OIL FILTER
No. Part Name Qty Remarks
Removing the starter motor and oil
filter
Remove the parts in the order listed.
A.C. magneto rotor
1 Starter idle gear 1
2 Starter idle gear shaft 1
3 Relief valve spring/steel ball 1/1
4 Chain plate 1
5 Timing chain guide(first cylinder) 1
6 Timing chain 1
7 Pump 1
8 Oil filter cover 1
9 O-ring 1
10 Oil filter cartridge 1
11 Starter motor 1
