CHASSIS

- 243-

SUSPENSION

Front Suspension

No. Part Name Qty Remarks

Removing the front suspension

1 Front shocker arm absorber (White) 2

Front shocker arm absorber (Black) 2

Front shocker arm absorber (Iron Grey) 2

2 Nut 2

3 Bolt, flange 2

4 Nut 2

5 Bar, stabilizer 1

6 Bushing, stabilizer 2
