Hisun HS800UTV - Page 258

To Next Page

To Previous Page

CHASSIS

- 244-

No. Part Name Qty Remarks

7 Cover, stabilizer 2

8 Bolt, flange 4

9 Joint, stabilizer 2

10 Bolt, flange 2

11 Nut, self-locking 2

12 Bolt, flange 2

13 Bush 2
