CHASSIS

- 196-

FRONT BRAKE CALIPER

No. Part Name

Qty Remarks

Removing front brake caliper

1 Brake caliper assembly 1

2 Bolt 4

3 Brake disc 1

4 Brake caliper assembly 1

5 Brake caliper, piston assembly 1

6 Brake caliper piston 2

7 Dust seal 2

8 Caliper piston seal 2

9 Bleed screw 1

10 Brake, pad 1
