Hisun HS800UTV - Chapter 6 Electrical Components; Electrical System Malfunction Inspection

ELECTRICAL COMPONENTS
- 281 -
ELECTRICAL SYSTEM MALFUNCTION INSPECTION
S/N Phenomenon Measure
1、 Check whether switches normal.
2、 Check whether cables damaged.
1 Abnormal lights
3、 Check whether lights damaged.
1、 Check whether four wheel drive switch normal.
2、 Check whether power divider damaged.
2
Fail to shift into
four-wheel-drive or
lock differential.
3、 Check whether differential mechanical conversion agency locked or
damaged.
1、 Check whether battery undercharge.
2、 Check whether starting motor damaged.
3、 Check whether CDI damaged.
4、 Check whether ignition coil normal.
5、 Check whether spark plug fouling or ablative.
6、 Check whether magneto ignition signal normal.
7、 Check whether carburetor plugged or damaged.
8、 Check whether air filter plugged.
3 Fail to electric start
9、 Check whether oil circuit smooth.
1、 Check whether sensor damaged.
2、 Check whether meter damaged.
4
Abnormal speed
indication between
meter and mileage.
3、 Check whether sensor surface polluted by iron scrap,
1、 Check whether neutral switch damaged.
2、 Check whether meter damaged.
5
Neutral indicator of
meter is not bright
3、 Check whether cable damaged.
1、 Check whether reverse switch damaged.
2、 Check whether meter damaged.
6
Reverse indicator
of meter is not
bright
3、 Check whether cable damaged.
1、 Check whether meter damaged.
2、 Check whether cable damaged.
7
Other indicators of
meter are not bright
3、 Check whether sensor or switch damaged.
1、 Check whether switch damaged.
2、 Check whether cable damaged.
8
Ignition switch
can not shut off.
3、 Check whether ECU damaged.
