Hisun HS800UTV - Disk Brake Components

To Next Page

To Previous Page

CHASSIS

- 194-

DISK BRAKE COMPONENTS

No. Part Name Qty Remarks

Removing brake components

1 Rear disc brake cylinder 1

2 Rear disc brake oil pipe assembly 1

Belt 3 （L=150）

Belt 4 （L=200）

Belt 3 （L=150）

6 Bolt ,flange M6×30 2

7 Bolt ,flange M6×20 4

8 Oil pipe clip 1, Front disc brake 8
