CHASSIS
- 251-
Rear Suspension
No. Part Name Qty Remarks
Removing the rear suspension
1 Rear shocker arm absorber (White) 2
Rear shocker arm absorber(Black) 2
Rear shocker arm absorber(Iron Grey) 2
2 Bolt, flange M10×1.25×70 2
3 Nut, self-locking M10x1.25 4
4 Bolt, flange M10×1.25×65 2
5 Bar, stabilizer 1
6 Bushing, stabilizer 2
7 Cover, stabilizer 2
8 Bolt, flange M8×15 4
9 Joint, stabilizer 2
10 Bolt, flange M10×1.25×45 4
11 Nut, self-locking M10x1.25 4
To Next Page
